Single Head Bridge Polishing MachineHLAP-1800桥式磨机
领跑智能制作新“石”代
Single Head Bridge Polishing MachineHLAP-1800桥式磨机
归属产品品牌:
隶属种别:板料钻研装置
想领会更多相干产物信息,请接洽咱们!
0594-2197723
hualongmc@163.com
销售技巧可留言版德律风数字,大家会与您约见!
Purchase please leave a message phone and email, we will contact you!
单头桥式抛光机
HLAP-1800 是一款桥式外表抛光机,具有主动换头功效,精度高、不变性强,用处普遍且效力高,是用于各类资料(如花岗岩、石英、大理石、石灰石等)的校准、哑光研磨、抛光、洗擦和盘式喷砂等任务的万能型装备。这款平板抛光机可设置装备摆设成多种差别的计划,具有两种差别的横向挪动尺寸(2220 毫米或 3200 毫米),具有主动换刀功效,另有机器式或电动式遏制装配……等等。跑道的长度能够按照您的须要和您的任务地区停止调剂。
Single Head Bridge Polishing Machine with Automatic Tool Change
HLAP-1800 is a bridge type surface polishing machine with automatic head change, accurate and stable, versatile and efficient, which is a true all rounder for calibration, matt grinding, polishing, brushing and disc blasting all common materials, such as granite, quartz, marble, limestone...
This slab polishing machine can be configurated in different solutions, with 2 different traverse capacities ( 2220 or 3200 mm ), with automatic tool change, with mechanical or motorized stop…etc.
The runway length is adjustable according to your needs and your workshop a꧃rea.
充分利用欧式
* 软质(🎃zhi)木🍌质(zhi)(大理(li)市石、缟红玛瑙(nao)、皂石等)用活套法兰克(ke)福头关闭镜面(mian)抛光
* 硬质的(de)石才(大理石、熔融石英(ying)(ying)晶体、熔融石英(ying)(ying)晶体岩等)用菲克特(te)头终止cnc精密(mi)机械加工(🃏gong)
Applications
* H𝓀ard stone (granite, qua🦋rtz, quartzite, etc.) polishing with fickert head
* Soft stone (marble, onyx, soapstone, etc.) p🤡olishing with frankfurt head
接洽咱们,获得完全计划!
Contact us to obtain the complete solution!
Hot Tags: hualong 5 axis cnc stone cutting machine, China, manufacturers, suppliers, factory, price, for sale, Granite Tile Polishing Machine, 5 Axis CNC Stone Saw, Double Blade Granite Quarry Machinery, Multi Balde Stone Cutting Machine, Automatic Stone Bridge Saw, CNC Sawjet
华隆系统,数车五轴联动桥切机,四轴桥切机,4+1桥切,5+1桥切,三轴桥切机,红外线桥切机,花岗岩切机,花岗岩加工生产处理厂场装配,花岗岩增加光泽机,花岗岩增加光泽装配,花岗岩加工生产处理厂之间,工作台面加工生产处理厂之间,水刀,水刀激光自动切割机,采矿场勘探装配,采矿场圆板锯,圆板双刀锯,采矿场机,采矿场锯。
|
产物型号
|
Name
|
单元
|
HLDM-1800
|
|
主机电功率
|
Power of main motor
|
kw
|
11
|
|
任务平台尺寸
|
Working platform dimensions
|
mm
|
3200 x 2000
|
|
须要气压
|
Air pressure required
|
Mpa
|
0.3 - 0.5
|
|
最大加工尺寸
|
Max. processing dimensions
|
mm
|
3200 x 3200 x 60
|
|
任务台倾斜
|
Working platform tilting degree
|
n°
|
0-85
|
|
抛光头转速
|
R.P.M. of polishing head
|
r/min
|
550
|
|
X轴进给速率
|
X axis feeding speed
|
mm/min
|
5300
|
|
Y轴进给速率
|
Y axis feeding speed
|
mm/min
|
4000
|
|
耗宇量
|
Air consumption
|
m3/min
|
0.15 - 0.3
|
|
耗水量
|
Water consumption
|
m3/h
|
4
|
|
总分量
|
Gross weight
|
kg
|
7000
|
|
机台尺寸
|
Dimension (L x W x H)
|
mm
|
6000 x 5000 x 2800
|
%>
浪漫小编提醒:倘若是想深刻领会非常多要素,产品规格、规范标准、市场价和治理规划,请商谈让我们。
